健康检查端点 /healthz 设计实践

 收录于 技能矩阵
   约 805 字   预计阅读 2 分钟
/2025/07/health-check-endpoint-healthz-design-practice/featured-image.jpeg

设计一个具有关键检查和独立外部监控的健康检查端点。

技巧
“Talk is cheap. Show me the code.” - Linus Torvalds

代码分享: https://github.com/mcsrainbow/mock-healthz-metrics

✨ 特性

  • /healthz:
    • 返回码: 健康 200, 异常 500
    • 输出: 纯文本, JSON
  • /metrics: Prometheus 指标
  • 两级健康检查:
    • 🔴 关键检查 影响整体健康状态:
      • 🔌 数据库连接: 核心依赖，必须健康
      • ⚙️ 配置服务: 核心依赖，必须健康
      • 🔁 内部 API billing, usage: 依赖上游服务DB + Config，上游失败时跳过
    • 🟡 外部检查 独立:
      • 🌍 外部 API alipay, sms: 独立运行，不影响整体健康状态
  • 依赖项具有内置错误概率和超时模拟
  • 完全兼容 Kubernetes 探针和 Prometheus 抓取
  • 依赖链:
    • 数据库 + 配置服务 → 内部 API → 整体健康状态
    • 外部 API → 仅独立监控

🚀 开始使用

1. 安装依赖

pip install bottle

2. 运行脚本

python mock-healthz-metrics.py
Service endpoints available:
  Healthcheck (Text):  http://0.0.0.0:8080/healthz
  Healthcheck (JSON):  http://0.0.0.0:8080/healthz?format=json
  Prometheus metrics:  http://0.0.0.0:8080/metrics

✅ 健康检查

纯文本

http://127.0.0.1:8080/healthz
http://127.0.0.1:8080/healthz?format=text

健康状态

CHECK                   STATUS  MESSAGE
----- Critical -----
db_connection           PASS    Database is connected
config_service          PASS    Config service is reachable
internal_api/billing    PASS    internal_api/billing OK (392ms)
internal_api/usage      PASS    internal_api/usage OK (348ms)
----- External -----
external_api/alipay     PASS    external_api/alipay OK (308ms)
external_api/sms        FAIL    external_api/sms timed out

异常状态

CHECK                   STATUS  MESSAGE
----- Critical -----
db_connection           PASS    Database is connected
config_service          PASS    Config service is reachable
internal_api/billing    PASS    internal_api/billing OK (253ms)
internal_api/usage      FAIL    internal_api/usage returned error
----- External -----
external_api/alipay     PASS    external_api/alipay OK (101ms)
external_api/sms        PASS    external_api/sms OK (183ms)

JSON 格式

http://127.0.0.1:8080/healthz?format=json

健康状态

{
  "status": "ok",
  "data": {
    "message": "All critical checks passed",
    "checks": {
      "critical": [
        {
          "name": "db_connection",
          "status": "ok",
          "message": "Database is connected"
        },
        {
          "name": "config_service",
          "status": "ok",
          "message": "Config service is reachable"
        },
        {
          "name": "internal_api/billing",
          "status": "ok",
          "message": "internal_api/billing OK (392ms)"
        },
        {
          "name": "internal_api/usage",
          "status": "ok",
          "message": "internal_api/usage OK (348ms)"
        }
      ],
      "external": [
        {
          "name": "external_api/alipay",
          "status": "ok",
          "message": "external_api/alipay OK (308ms)"
        },
        {
          "name": "external_api/sms",
          "status": "error",
          "message": "external_api/sms timed out"
        }
      ]
    }
  }
}

异常状态

{
  "status": "error",
  "data": {
    "message": "Critical checks failed",
    "checks": {
      "critical": [
        {
          "name": "db_connection",
          "status": "ok",
          "message": "Database is connected"
        },
        {
          "name": "config_service",
          "status": "ok",
          "message": "Config service is reachable"
        },
        {
          "name": "internal_api/billing",
          "status": "ok",
          "message": "internal_api/billing OK (253ms)"
        },
        {
          "name": "internal_api/usage",
          "status": "error",
          "message": "internal_api/usage returned error"
        }
      ],
      "external": [
        {
          "name": "external_api/alipay",
          "status": "ok",
          "message": "external_api/alipay OK (101ms)"
        },
        {
          "name": "external_api/sms",
          "status": "ok",
          "message": "external_api/sms OK (183ms)"
        }
      ]
    }
  }
}

📈 Prometheus

http://127.0.0.1:8080/metrics

配置

scrape_configs:
  - job_name: 'mock-healthz-metrics'
    static_configs:
      - targets: ['127.0.0.1:8080']

默认抓取 http://127.0.0.1:8080/metrics 链接。

指标

健康状态

# HELP healthcheck_status Health check status (1=ok,0=error)
# TYPE healthcheck_status gauge
healthcheck_status{check="db_connection",type="critical"} 1
healthcheck_status{check="config_service",type="critical"} 1
healthcheck_status{check="internal_api/billing",type="critical"} 1
healthcheck_status{check="internal_api/usage",type="critical"} 1
healthcheck_status{check="external_api/alipay",type="external"} 1
healthcheck_status{check="external_api/sms",type="external"} 0

异常状态

# HELP healthcheck_status Health check status (1=ok,0=error)
# TYPE healthcheck_status gauge
healthcheck_status{check="db_connection",type="critical"} 1
healthcheck_status{check="config_service",type="critical"} 1
healthcheck_status{check="internal_api/billing",type="critical"} 0
healthcheck_status{check="internal_api/usage",type="critical"} 1
healthcheck_status{check="external_api/alipay",type="external"} 1
healthcheck_status{check="external_api/sms",type="external"} 1

🐳 Kubernetes

对于 Kubernetes livenessProbe 和 readinessProbe:

❯ curl -I http://127.0.0.1:8080/healthz
HTTP/1.0 200 OK
Date: Fri, 18 Jul 2025 03:43:31 GMT
Server: WSGIServer/0.2 CPython/3.11.11
Content-Type: text/plain
Content-Length: 444

❯ curl -I http://127.0.0.1:8080/healthz
HTTP/1.0 500 Internal Server Error
Date: Fri, 18 Jul 2025 03:43:36 GMT
Server: WSGIServer/0.2 CPython/3.11.11
Content-Type: text/plain
Content-Length: 438
livenessProbe:
  httpGet:
    path: /healthz
    port: 8080
  initialDelaySeconds: 10
  periodSeconds: 30
  failureThreshold: 5
  timeoutSeconds: 5

readinessProbe:
  httpGet:
    path: /healthz
    port: 8080
  initialDelaySeconds: 5
  periodSeconds: 20
  failureThreshold: 3
  successThreshold: 2
  timeoutSeconds: 2

关于更详细的探针设计，请参考文章: Kubernetes 容器健康检查和优雅终止。

📌 注意事项

  • 此脚本使用随机化逻辑来模拟服务不稳定性
  • 对于生产环境使用，请用真实的健康检查实现替换模拟逻辑（例如，数据库 ping、HTTP 客户端调用等）
更新于 2025-07-18
