快速实践 Debezium MySQL Kafka CDC

 收录于 技能矩阵
   约 746 字   预计阅读 2 分钟
/2025/09/quickstart-debezium-mysql-kafka-cdc/featured-image.jpeg

使用 Docker、KRaft 和 Kafdrop 快速实践最小化的 Debezium MySQL Kafka CDC (Change Data Capture)。

搭建基础服务

  1. 创建 docker-compose 文件

    mkdir debezium-amd64
cd debezium-amd64
    vim docker-compose.yml
    services:
  kafka:
    image: bitnami/kafka:3.7
    platform: linux/amd64
    ports:
      - "9092:9092"
    environment:
      # enable KRaft (no Zookeeper)
      - KAFKA_ENABLE_KRAFT=yes
      - KAFKA_CFG_NODE_ID=1
      - KAFKA_CFG_PROCESS_ROLES=broker,controller
      - KAFKA_CFG_LISTENERS=PLAINTEXT://:9092,CONTROLLER://:9093
      - KAFKA_CFG_ADVERTISED_LISTENERS=PLAINTEXT://kafka:9092
      - KAFKA_CFG_CONTROLLER_LISTENER_NAMES=CONTROLLER
      - KAFKA_CFG_CONTROLLER_QUORUM_VOTERS=1@kafka:9093
      - KAFKA_CFG_AUTO_CREATE_TOPICS_ENABLE=true
      - ALLOW_PLAINTEXT_LISTENER=yes

  connect:
    image: quay.io/debezium/connect:3.2
    platform: linux/amd64
    ports:
      - "8083:8083"
    environment:
      - BOOTSTRAP_SERVERS=kafka:9092
      - GROUP_ID=1
      - CONFIG_STORAGE_TOPIC=connect_configs
      - OFFSET_STORAGE_TOPIC=connect_offsets
      - STATUS_STORAGE_TOPIC=connect_statuses
      - KEY_CONVERTER=org.apache.kafka.connect.json.JsonConverter
      - VALUE_CONVERTER=org.apache.kafka.connect.json.JsonConverter
      - KEY_CONVERTER_SCHEMAS_ENABLE=false
      - VALUE_CONVERTER_SCHEMAS_ENABLE=false
    depends_on:
      - kafka

  kafdrop:
    image: obsidiandynamics/kafdrop:4.2.0
    platform: linux/amd64
    ports:
      - "9000:9000"
    environment:
      - KAFKA_BROKERCONNECT=kafka:9092
    depends_on:
      - kafka

  mysql:
    image: mysql:8.0
    platform: linux/amd64
    ports:
      - "3306:3306"
    environment:
      - MYSQL_ROOT_PASSWORD=debezium
      - MYSQL_USER=debezium
      - MYSQL_PASSWORD=dbz
      - MYSQL_DATABASE=inventory
    command: >
      --server-id=857
      --log-bin=binlog
      --binlog_format=ROW
      --binlog_row_image=FULL
      --gtid_mode=ON
      --enforce-gtid-consistency=ON
      --binlog_expire_logs_seconds=600
    volumes:
      - ./mysql-init.sql:/docker-entrypoint-initdb.d/mysql-init.sql
    vim mysql-init.sql
    -- ensure the database exists and is selected
CREATE DATABASE IF NOT EXISTS inventory;
USE inventory;

-- minimal demo table (keep it simple for CDC)
CREATE TABLE IF NOT EXISTS customers (
  id INT PRIMARY KEY AUTO_INCREMENT,
  first_name VARCHAR(50),
  last_name  VARCHAR(50),
  email      VARCHAR(100),
  created_at TIMESTAMP DEFAULT CURRENT_TIMESTAMP
);

-- seed data for snapshot
INSERT INTO customers (first_name, last_name, email) VALUES
('Alice', 'Smith', 'alice@example.com'),
('Bob',   'Johnson', 'bob@example.com');
    vim register-mysql.json
    {
  "name": "mysql-inventory-connector",
  "config": {
    "connector.class": "io.debezium.connector.mysql.MySqlConnector",
    "tasks.max": "1",

    "database.hostname": "mysql",
    "database.port": "3306",
    "database.user": "debezium",
    "database.password": "dbz",

    "database.server.id": "857",

    "topic.prefix": "mysql_server",
    "database.include.list": "inventory",
    "table.include.list": "inventory.customers",

    "snapshot.mode": "initial",
    "snapshot.locking.mode": "none",
    "include.schema.changes": "false",
    "tombstones.on.delete": "false",

    "schema.history.internal.kafka.bootstrap.servers": "kafka:9092",
    "schema.history.internal.kafka.topic": "schema-changes.inventory"
  }
}
    ls -1
    docker-compose.yml
mysql-init.sql
register-mysql.json

  2. 启动服务

    docker-compose up -d
    [+] Running 5/5
✔ Network debezium-amd64_default      Created
✔ Container debezium-amd64-mysql-1    Started
✔ Container debezium-amd64-kafka-1    Started
✔ Container debezium-amd64-kafdrop-1  Started
✔ Container debezium-amd64-connect-1  Started

配置 Source Connector

  1. 授权 Source Connector 访问 MySQL

    docker-compose exec -T mysql mysql -uroot -pdebezium -e "
GRANT SELECT, RELOAD, SHOW DATABASES, REPLICATION SLAVE, REPLICATION CLIENT, LOCK TABLES ON *.* TO 'debezium'@'%';
FLUSH PRIVILEGES;"

  2. 注册 Source Connector

    curl -s -X POST http://localhost:8083/connectors \
  -H "Content-Type: application/json" \
  -d @register-mysql.json

  3. 更新 Source Connector 配置（可选）

    jq '.config' register-mysql.json | \
curl -s -X PUT http://localhost:8083/connectors/mysql-inventory-connector/config \
  -H "Content-Type: application/json" \
  -d @- | jq .

  4. 检查 Source Connector 状态

    curl -s localhost:8083/connectors/mysql-inventory-connector/status | jq .
    {
  "name": "mysql-inventory-connector",
  "connector": {
    "state": "RUNNING",
    "worker_id": "192.168.97.5:8083"
  },
  "tasks": [
    {
      "id": 0,
      "state": "RUNNING",
      "worker_id": "192.168.97.5:8083"
    }
  ],
  "type": "source"
}

  5. 触发 CDC 事件

    插入/更新/删除一些数据行来查看增/改/删事件

    docker-compose exec -T mysql mysql -udebezium -pdbz -e "USE inventory;
INSERT INTO customers (first_name,last_name,email) VALUES ('Charlie','Wang','charlie@example.com');
UPDATE customers SET email='alice_new@example.com' WHERE first_name='Alice';
DELETE FROM customers WHERE first_name='Bob';"

  6. 在 Kafdrop 上查看主题

    访问 http://localhost:9000

    查看主题 mysql_server.inventory.customers

    查看新事件 "op":"c" / "op":"u" / "op":"d"

    /2025/09/quickstart-debezium-mysql-kafka-cdc/kafdrop_topic_msg_c_u_d.png

配置 Sink Connector

  1. 授权 Sink Connector 访问 MySQL

    docker-compose exec -T mysql mysql -uroot -pdebezium -e "
CREATE USER IF NOT EXISTS 'sink'@'%' IDENTIFIED BY 'sinkpw';
GRANT SELECT, INSERT, UPDATE, DELETE, CREATE, ALTER ON inventory.* TO 'sink'@'%';
FLUSH PRIVILEGES;"
    vim register-jdbc-sink.json
    {
  "name": "jdbc-sink-mysql",
  "config": {
    "connector.class": "io.debezium.connector.jdbc.JdbcSinkConnector",
    "tasks.max": "1",
    "topics": "mysql_server.inventory.customers",

    "connection.url": "jdbc:mysql://mysql:3306/inventory",
    "connection.username": "sink",
    "connection.password": "sinkpw",

    "insert.mode": "upsert",
    "delete.enabled": "true",
    "primary.key.mode": "record_key",
    "primary.key.fields": "id",

    "schema.evolution": "basic",
    "collection.name.format": "customers_mirror",
    "consumer.override.auto.offset.reset": "earliest"
  }
}

  2. 注册 Sink Connector

    curl -s -X POST http://localhost:8083/connectors \
  -H "Content-Type: application/json" \
  -d @register-jdbc-sink.json

  3. 更新 Sink Connector（可选）

    jq '.config' register-jdbc-sink.json | \
curl -s -X PUT http://localhost:8083/connectors/mysql-inventory-connector/config \
  -H "Content-Type: application/json" \
  -d @- | jq .

  4. 检查 Sink Connector 状态

    curl -s http://localhost:8083/connectors/jdbc-sink-mysql/status | jq .
    {
  "name": "jdbc-sink-mysql",
  "connector": {
    "state": "RUNNING",
    "worker_id": "192.168.97.5:8083"
  },
  "tasks": [
    {
      "id": 0,
      "state": "RUNNING",
      "worker_id": "192.168.97.5:8083"
    }
  ],
  "type": "sink"
}

验证端到端数据同步

  1. 检查源表

    docker-compose exec -T mysql mysql -usink -psinkpw -e "SELECT * FROM inventory.customers;"
    id  first_name  last_name  email                  created_at
1   Alice       Smith      alice_new@example.com  2025-09-19 01:50:16
3   Charlie     Wang       charlie@example.com    2025-09-19 01:58:59

  2. 检查镜像表

    docker-compose exec -T mysql mysql -usink -psinkpw -e "SELECT * FROM inventory.customers_mirror;"
    id  first_name  last_name  email                  created_at
1   Alice       Smith      alice_new@example.com  2025-09-19 01:50:16
3   Charlie     Wang       charlie@example.com    2025-09-19 01:58:59
