Health Check Endpoint /healthz Design Practice

Damon included in Skills

2025-07-18 625 words 3 minutes

/2025/07/health-check-endpoint-healthz-design-practice/featured-image.jpeg

Contents

Health check endpoint with dependency-aware critical checks and independent external monitoring.

Tip

“Talk is cheap. Show me the code.” - Linus Torvalds

Code Sharing: https://github.com/mcsrainbow/mock-healthz-metrics

✨ Features

/healthz:
- Return code: Healthy 200, Unhealthy 500
- Output: Plaintext, JSON
/metrics: Prometheus metrics
Two-tier health checks:
- 🔴 Critical checks Affect overall health status:
  - 🔌 Database connection: Core dependency, must be healthy
  - ⚙️ Config service: Core dependency, must be healthy
  - 🔁 Internal APIs billing, usage: Depend on upstream services (DB + Config), skipped if upstream fails
- 🟡 External checks Independent:
  - 🌍 External APIs alipay, sms: Run independently, don’t affect overall health status
Dependencies have built-in error probability and timeout simulation
Fully compatible with Kubernetes probes and Prometheus scraping
Dependency Chain:
- Database + Config Service → Internal APIs → Overall Health Status
- External APIs → Independent Monitoring Only

🚀 Getting Started

1. Install dependencies

pip install bottle

2. Run the script

python mock-healthz-metrics.py


Service endpoints available:
  Healthcheck (Text):  http://0.0.0.0:8080/healthz
  Healthcheck (JSON):  http://0.0.0.0:8080/healthz?format=json
  Prometheus metrics:  http://0.0.0.0:8080/metrics

✅ Healthcheck

Plaintext

http://127.0.0.1:8080/healthz
http://127.0.0.1:8080/healthz?format=text

Healthy





HEALTH CHECK SNAPSHOT [2025-07-18 11:03:15]
-------------------------------------------
CHECK                   STATUS  MESSAGE
----- CRITICAL -----
db_connection           ✔       Database is connected
config_service          ✔       Config service is reachable
internal_api/billing    ✔       internal_api/billing OK (392ms)
internal_api/usage      ✔       internal_api/usage OK (348ms)
----- EXTERNAL -----
external_api/alipay     ✔       external_api/alipay OK (308ms)
external_api/sms        ✖       external_api/sms timed out

Unhealthy





HEALTH CHECK SNAPSHOT [2025-07-18 11:05:27]
-------------------------------------------
CHECK                   STATUS  MESSAGE
----- CRITICAL -----
db_connection           ✔       Database is connected
config_service          ✔       Config service is reachable
internal_api/billing    ✔       internal_api/billing OK (253ms)
internal_api/usage      ✖       internal_api/usage returned error
----- EXTERNAL -----
external_api/alipay     ✔       external_api/alipay OK (101ms)
external_api/sms        ✔       external_api/sms OK (183ms)

JSON Format

http://127.0.0.1:8080/healthz?format=json

Healthy





{
  "status": "ok",
  "data": {
    "message": "All critical checks passed",
    "snapshot_time": "2025-07-18 11:03:15",
    "checks": {
      "critical": [
        {
          "name": "db_connection",
          "status": "ok",
          "message": "Database is connected"
        },
        {
          "name": "config_service",
          "status": "ok",
          "message": "Config service is reachable"
        },
        {
          "name": "internal_api/billing",
          "status": "ok",
          "message": "internal_api/billing OK (392ms)"
        },
        {
          "name": "internal_api/usage",
          "status": "ok",
          "message": "internal_api/usage OK (348ms)"
        }
      ],
      "external": [
        {
          "name": "external_api/alipay",
          "status": "ok",
          "message": "external_api/alipay OK (308ms)"
        },
        {
          "name": "external_api/sms",
          "status": "error",
          "message": "external_api/sms timed out"
        }
      ]
    }
  }
}

Unhealthy





{
  "status": "error",
  "data": {
    "message": "Some critical checks failed",
    "snapshot_time": "2025-07-18 11:05:27",
    "checks": {
      "critical": [
        {
          "name": "db_connection",
          "status": "ok",
          "message": "Database is connected"
        },
        {
          "name": "config_service",
          "status": "ok",
          "message": "Config service is reachable"
        },
        {
          "name": "internal_api/billing",
          "status": "ok",
          "message": "internal_api/billing OK (253ms)"
        },
        {
          "name": "internal_api/usage",
          "status": "error",
          "message": "internal_api/usage returned error"
        }
      ],
      "external": [
        {
          "name": "external_api/alipay",
          "status": "ok",
          "message": "external_api/alipay OK (101ms)"
        },
        {
          "name": "external_api/sms",
          "status": "ok",
          "message": "external_api/sms OK (183ms)"
        }
      ]
    }
  }
}

📈 Prometheus

http://127.0.0.1:8080/metrics

Config


scrape_configs:
  - job_name: 'mock-healthz-metrics'
    static_configs:
      - targets: ['127.0.0.1:8080']

Scrape http://127.0.0.1:8080/metrics by default.

Metrics

Healthy





# HELP healthcheck_status Health check status (1=ok,0=error)
# TYPE healthcheck_status gauge
healthcheck_status{check="db_connection",type="critical"} 1
healthcheck_status{check="config_service",type="critical"} 1
healthcheck_status{check="internal_api/billing",type="critical"} 1
healthcheck_status{check="internal_api/usage",type="critical"} 1
healthcheck_status{check="external_api/alipay",type="external"} 1
healthcheck_status{check="external_api/sms",type="external"} 0

Unhealthy





# HELP healthcheck_status Health check status (1=ok,0=error)
# TYPE healthcheck_status gauge
healthcheck_status{check="db_connection",type="critical"} 1
healthcheck_status{check="config_service",type="critical"} 1
healthcheck_status{check="internal_api/billing",type="critical"} 1
healthcheck_status{check="internal_api/usage",type="critical"} 0
healthcheck_status{check="external_api/alipay",type="external"} 1
healthcheck_status{check="external_api/sms",type="external"} 1

🐳 Kubernetes

For Kubernetes livenessProbe and readinessProbe:





❯ curl -I http://127.0.0.1:8080/healthz
HTTP/1.0 200 OK
Date: Fri, 18 Jul 2025 03:03:31 GMT
Server: WSGIServer/0.2 CPython/3.11.11
Content-Type: text/plain
Content-Length: 444

❯ curl -I http://127.0.0.1:8080/healthz
HTTP/1.0 500 Internal Server Error
Date: Fri, 18 Jul 2025 03:05:36 GMT
Server: WSGIServer/0.2 CPython/3.11.11
Content-Type: text/plain
Content-Length: 438





livenessProbe:
  httpGet:
    path: /healthz
    port: 8080
  initialDelaySeconds: 10
  periodSeconds: 30
  failureThreshold: 5
  timeoutSeconds: 5

readinessProbe:
  httpGet:
    path: /healthz
    port: 8080
  initialDelaySeconds: 5
  periodSeconds: 20
  failureThreshold: 3
  successThreshold: 2
  timeoutSeconds: 2

For more detailed probe design, please refer to the article: Kubernetes Container Healthcheck and Graceful Termination.

📌 Notes

This script uses randomized logic to simulate service instability
For production usage, replace simulation logic with real health check implementations (e.g., database pings, HTTP client calls, etc.)
